DC12V 1CH Receiver Board
1.Working Voltage: DC12V more or less than 10% 2.Current:Standby≤10mA,Working ≤128mA 3.Working Temperature: -10’C—+60’C 4.Receiver Frequency: 315MHz/433MHZ 5.Receiving Sensitivity: -105dB 6.Output State: Switching Value 7.Max Load:10A Relay, Resistive load≤8A,Inductive load≤3A 8.Receiver Board Size:55×31×16mm 9.Case Size:73×36×24mm Learning Code: Add transmitter by the Learning Button on the receiver Output State: It is adjusted by the Jumper on the Receiver Board, (before you change it .you need turn OFF the power. Until you have changed it, then turn ON the power again, or the State will not be changed) Momentary———-Jumper on “1&2” Toggle—————-Jumper “2&3” Latched————–Take away the Jumper or put the Jumper on 1 Pin Momentary————Press the Transmitter button and keep, the receiver relay is ON, release button, the receiver relay is OFF, Toggle—————Press transmitter button for 1 time, the receiver relay is ON, press button again, the receiver relay is OFF, Latched——————Press transmitter button A, the receiver relay A is ON, Press Button B, the Receiver is OFF Learning Method Input power for the Receiver .Press the Learning Button until the Led indicator ON. Then press transmitter, the Led indicator flash fast, it mean learning successfully. Clearing Code Keeping press the Learning Button on the receiver until the LED indicator ON and flash fast, it mean the code have been cleared successfully.
Transmitting Distance: 200-3000m
220V 1Channel Radio Wireless Switch for Light Lamp LED SMD ON OFF Wireless Receiver&Transmitter 10A Momenrary Toggle Latched
US$ 17.50/set |
220V 1CH Wireless Switch for Light Lamp LED SMD ON OFF Wireless Remote Control Receiver&Transmitter10A Momenrary Toggle Latched
US$ 18.50/set |
220V 1Channel Radio Wireless Switch for Light Lamp LED SMD ON OFF Wireless Receiver&Transmitter 10A Momenrary Toggle Latched
US$ 18.30/set |
RF 220V 30A 3000WWireless Remote Control Switch System315/433 light/Lamp LED water pump electrical machine ON OF Latched
US$ 15.00/set |
3000M Long Range Remote Control Switch System 220V RF 4 Receivers+1Transmitter Through Wall Remote Control For LED Light Lamp
US$ 32.00/piece |
220V Wireless Switch Remote Control System 30A 3000W 315/433 light/Lamp LED water pump electrical machine ON OF Momentary
US$ 13.00/set |
AC220V 30A 3000W RF Wireless Remote Control Switch Transmitter&Receiver System For Light/LED/Lamp Water Pump electrical machine
US$ 15.00/set |
wireless switch remote control switch system &controller 3000M 220V 1CH(Channel) 4Receiver&1Transmitter 1000W Toggle /Momentary
US$ 35.00/set |
DC12V RF Wireless Switch Wireless remote control system1transmitter+6receiver10A 1CH Toggle Momentary Latched Learning Code
