Attention:
This Xiaomi mini WIFI only White color IN STOCK now. NO black color optional.
if you want the black one,pls order by this link,
http://www.aliexpress.com/store/product/100-Original-Xiaomi-Router-Mini-MI-Router-Smart-Router-Black-Dual-band-2-4GHz-5GHz-Maximum/600815_32344730202.html
You can browser link as following video to setup the Xiaomi Router:
1.https://www.youtube.com/watch?v=z7wSs3xI7FA
2.https://www.youtube.com/watch?v=xg-d0cyWOcQ
More Languages introduction:
http://www.aliexpress.com/store/product/Xiaomi-Router-mult-language-Introduction/600815_32422538149.html
Hardware Configuration
–CPU : MT7620A 580MHz
–ROM : 16MB SPI Flash
–Memory:128MB DDR2
–Band and Rate: 2.4G WiFi 2*2 #Max Rate 300Mbps#
5G Wifi 2*2 #Max Rate 867Mbps#
–Antenna : External Dual Band *2
Machine Interface
–WAN Ports :1 10/100M #Auto MDI/MPX#
–LAN Ports : 2 10/100M #Auto MDI/MPX#
–USB Ports : 1
–Input Ports : 1
Wireless Parameters
–Band : 2.4GHz and 5.0GHz
–Wireless Channel :2.4GHz Channel: 1,2,3,4,5,6,7,8,9,10,11,12,13
5GHz Channel: 149,153,157,161,165
5GHz DFS Channel:36,40,44,48,52,56,60,64
–Modulation : 11b:DSSS:DBPSK#1Mbps#,DQPSK#2Mbps#,CCK#5.5/11Mbps#
11a/g:OFDM:BPSK#6/9Mbps#,QPSK#12/18Mbps#,16QAM#24/36Mbps#,Q64QAM#48/54Mbps#
11n:MIMO-OFDM:BPSK,QPSK,16QAM,64QAM. QRate Set:MCS0~MCS15
11ac:MIMO-OFDM:BPSK,QQPSK,16QAM,64QAM,256QAM. Q Rate Set:MCS0~MCS9
-Receiver sensitivity : 11Mbps:≤-90dBm,54 Mbps:≤-72dBm,
HT20 QMCS7:≤-69dBm,
QHT40 MCS7:≤-66dBm,
VHT20 MCS8:≤-65dBm,
Q VHT40 MCS9:≤-60dBm,
QVHT80 MCS9:≤-58 dBm
Software Configuration
–Operation System : Mini Wift ROM # base on OpenWRT#
–Support : Web,Windows ,Android ,MacOS , IOS
–Protocol Standards : IEEE 802.11a/b/g/n/ac,IEEE 802.3/3u
–Certification standards : GB9254-2008 YD/T993-1998 GB4943.1-2011
1*Original Xiaomi Router Mini(White color)
1*Charger #12V / 1A #
1*Instructions(Manual only in Chinese)
1*Warranty Card
1*Adapter free
